MG1000 Series

Key Features

• 2 line display HMI with keypad
• UL 508A listed control panel
• NEMA 12 rated enclosure
• Compliance with NFPA99
• Molded case circuit breaker disconnects for each motor with through-the-door lockable mechanism
• Dual 120V control circuit transformer with fused primary/secondary and dedicated breaker per pump
• Pressure switch connection for backup system operation should primary control circuit fail*
• Lighted H-O-A switches and magnetic starters with three-leg thermal overload for each pump
• 2 line super-twisted nematic LCD display with keypad shows operating status, pump run hours, faults, system pressure and alarms
• High temperature shutdown for each pump
• PLC controller with control logic to start the lag pump automatically if the lead pump fails
• Logic automatically removes a failed or switched-off pump from the duty sequence
• All components are non-proprietary and can be replaced with standard off-the-shelf components**
• Normally open and normally closed dry contact for remote monitoring of NFPA 99 alarm points
